Illustrated parts catalog
Maintenance and Service Guide 3–13
504593-004 Broadcom BCM4312 802.11b/g WLAN module plus Bluetooth plus 2 antennas for use in
Afghanistan, Albania, Algeria, Andorra, Angola, Antigua and Barbuda, Argentina, Armenia, Aruba,
Australia, Austria, Azerbaijan, the Bahamas, Bahrain, Bangladesh, Barbados, Belarus, Belgium,
Belize, Benin, Bermuda, Bhutan, Bolivia, Bosnia and Herzegovina, Botswana, Brazil, the British
Virgin Islands, Brunei, Bulgaria, Burkina Faso, Burundi, Cameroon, Cape Verde, the Central African
Republic, Chad, Chile, the People's Republic of China, Colombia, Comoros, the Congo, Costa Rica,
Croatia, Cyprus, the Czech Republic, Denmark, Djibouti, Dominica, the Dominican Republic, East
Timor, Ecuador, Egypt, El Salvador, Equitorial Guinea, Eritrea, Estonia, Ethiopia, Fiji, Finland,
France, French Guiana, Gabon, Gambia, Georgia, Germany, Ghana, Gibraltar, Greece, Grenada,
Guadeloupe, Guatemala, Guinea, Guinea-Bissau, Guyana, Haiti, Honduras, Hong Kong, Hungary,
Iceland, India, Ireland, Israel, Italy, the Ivory Coast, Jamaica, Jordan, Kazakhstan, Kenya, Kiribati,
Kyrgyzstan, Laos, Latvia, Lebanon, Lesotho, Liberia, Liechtenstein, Lithuania, Luxembourg,
Macedonia, Madagascar, Malawi, Malaysia, the Maldives, Mali, Malta, the Marshall Islands,
Martinique, Mauritania, Mauritius, Mexico, Micronesia, Monaco, Mongolia, Montenegro, Morocco,
Mozambique, Namibia, Nauru, Nepal, the Nether Antilles, the Netherlands, New Zealand,
Nicaragua, Niger, Nigeria, Norway, Oman, Pakistan, Palau, Panama, Papua New Guinea, Paraguay,
Peru, the Philippines, Poland, Portugal, the Republic of Moldova, Romania, Russia, Rwanda,
Samoa, San Marino, Sao Tome and Principe, Saudi Arabia, Senegal, Serbia, the Seychelles, Sierra
Leone, Singapore, Slovakia, Slovenia, the Solomon Islands, Somalia, South Africa, South Korea,
Spain, Sri Lanka, St. Kitts and Nevis, St. Lucia, St. Vincent and the Grenadines, Suriname,
Swaziland, Sweden, Switzerland, Taiwan, Tajikistan, Tanzania, Togo, Tonga, Trinidad and Tobago,
Tunisia, Turkey, Turkmenistan, Tuvalu, Uganda, Ukraine, the United Arab Emirates, the United
Kingdom, Uruguay, Uzbekistan, Vanuatu, Venezuela, Vietnam, Yemen, Zaire, Zambia, and
Zimbabwe
509409-002 4-GB memory module (DDR2, 800-MHz, PC2-6400, 1-DIMM)
509410-002 2-GB memory module (DDR2, 800-MHz, PC2-6400, 1-DIMM)
509411-002 1-GB memory module (DDR2, 800-MHz, PC2-6400, 1-DIMM)
509412-002 250-GB, 7200-rpm hard drive (includes left and right bracket rails, connector cable, Mylar cover with
tab, and four rubber isolators) (select models only)
509413-002 320-GB, 7200-rpm hard drive (includes left and right bracket rails, connector cable, Mylar cover with
tab, and four rubber isolators) (select models only)
509414-002 250-GB, 5400-rpm hard drive (includes left and right bracket rails, connector cable, Mylar cover with
tab, and four rubber isolators)
509415-002 320-GB, 5400-rpm hard drive (includes left and right bracket rails, connector cable, Mylar cover with
tab, and four rubber isolators)
509417-002 500-GB, 5400-rpm hard drive (includes left and right bracket rails, connector cable, Mylar cover with
tab, and four rubber isolators)
509419-002 DVD±RW and CD-RW SuperMulti Double-Layer Combo Drive
509421-002 Blu-ray ROM with LightScribe DVD±R/RW SuperMulti Double-Layer Drive
510100-001 Modem module for use in all countries and regions except Australia and New Zealand
510100-011 Modem module for use only in Australia and New Zealand
511890-001 Plastics Kit (see “Plastics Kit” on page 3-9)
511892-001 Audio/infrared board
512361-001 Display Rubber Kit (includes display bezel rubber screw covers)
512362-001 Display Screw Kit
512364-001 Display bezel (includes logo and internal display switch actuator magnet)
512834-001 Power button board (includes cable)
516497-001 USB board (includes cable)
(Continued)
Spare part number Description
