Table 7-12 Rear view of printer (continued)
Feature Description
3 DSL/ADSL lter.
4
Use a minimum 26 AWG phone cord to connect to the port on the printer.
CAUTION: To reduce the risk of re, use only No. 26 AWG or larger (For example, 24 AWG) UL
Listed or CSA Certied Telecommunications Line Cord.
You might need to connect the phone cord to your country/region adapter.
5 DSL/ADSL modem.
6 Computer.
7 Telephone.
NOTE: You need to purchase a parallel splitter. A parallel splitter has one RJ-11 port on the front and two
RJ-11 ports on the back. Do not use a 2–line phone splitter, a serial splitter, or a parallel splitter which has two
RJ-11 ports on the front and a plug on the back.
Figure 7-3 Example of a parallel splitter
Set up the printer with a computer DSL/ADSL modem
Follow these steps to set up the printer with a computer DSL/ADSL modem.
1. Obtain a DSL lter from your DSL provider.
NOTE: Phones in other parts of the home/oice sharing the same phone number with DSL service need to
be connected to additional DSL lters to avoid noise when making voice calls.
2. Connect one end of the phone cord to your telephone wall jack, then connect the other end to the Fax
port on the back of the printer.
NOTE: You might need to connect the phone cord to your country/region adapter.
3. If you have a parallel-type phone system, connect a phone to the Fax port on the back of the printer.
4. Connect the DSL lter to the parallel splitter.
5. Connect the DSL modem to the parallel splitter.
6. Connect the parallel splitter to the wall jack.
When the phone rings, the printer automatically answers after the number of rings you set in the Rings to
Answer setting. The printer begins emitting fax reception tones to the sending fax machine and receives the fax.
If you encounter problems setting up the printer with optional equipment, contact your local service provider or
vendor for further assistance.
Set up the printer with a computer DSL/ADSL modem
67
