Speakers
Description Spare part number
Speaker Kit (includes left and right speakers and cable) 681821-001
Before removing the speakers, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 32).
5. Remove the service door (see
Service door on page 33).
6. Remove the optical drive (see
Optical drive on page 34).
7. Remove the hard drive (see {Xref Error! Target does not exist.})
8. Remove the keyboard (see
Keyboard on page 43).
9. Remove the top cover (see
Top cover on page 47).
Remove the speakers:
1. There are two clips that hold the left speaker in place (1).
NOTE: A previously removed top cover screw also secures the right speaker in place.
2. Rotate and lift the left speaker from the top cover (2). Release the speaker cable from the clips
built into the top cover.
3. Remove one PM 2.5 x 3.5 screw (3) from the right speaker that secures it to the top cover (2).
NOTE: This screw also secures the power button board to the top cover.
50 Chapter 4 Removal and replacement procedures
