Table 6-7 System board descriptions and part numbers
Description Spare part number
System board (includes the processor, replacement thermal material, and the Chrome operating
system)
MediaTek MT8186 processor, 8 GB system memory, 64 GB eMMC memory P24052-001
MediaTek MT8186 processor, 8 GB system memory, 32 GB eMMC memory P24051-001
MediaTek MT8186 processor, 4 GB system memory, 64 GB eMMC memory P24050-001
MediaTek MT8186 processor, 4 GB system memory, 32 GB eMMC memory P24049-001
Before removing the system board, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 25).
2. Remove the bottom cover (see Bottom cover on page 32).
3. Remove the battery (see Removing and reinstalling the same battery on page 26).
4. Remove the WLAN module (see WLAN module on page 36).
Remove the system board:
1. Disconnect the following cables from the system board:
● Display cable (ZIF) (1)
● Large I/O board cable (ZIF) (2)
● Large I/O board cable (ZIF) (3)
● Large I/O board cable (ZIF) (4)
● Speaker cable (5)
● Keyboard cable (ZIF) (6)
● Touchpad cable (ZIF) (7)
● Small I/O board cable (ZIF) (8)
42
Chapter 6 Removal and replacement procedures for authorized service provider parts
