d. Lift the inside of the board up, and then pull the board (5) into the computer to remove it.
To install the I/O boards, reverse this procedure.
Heat sink
To remove the heat sink, use these procedures and illustrations.
Table 6-6
Heat sink description and part number
Description Spare part number
Heat sink (includes replacement thermal material) P22934-001
Before removing the heat sink, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 25).
2. Remove the bottom cover (see Bottom cover on page 32).
3. Remove the battery (see Removing and reinstalling the same battery on page 26).
Remove the heat sink:
1. Remove the five Phillips M2.0 × 3.5 screws (1) that secure the heat sink to the system board.
40
Chapter 6 Removal and replacement procedures for authorized service provider parts
