Table 6-3 Touchpad descriptions and part numbers (continued)
Description Spare part number
Touchpad bracket (included in the Bracket Kit) P24054-001
Touchpad protective tape P24055-001
Before removing the touchpad, follow these steps:
1. Prepare the computer for disassembly (see Preparation for disassembly on page 25).
2. Remove the bottom cover (see Bottom cover on page 32).
3. Remove the battery (see Removing and reinstalling the same battery on page 26).
Remove the touchpad:
NOTE: You do not have to remove the touchpad bracket before removing the touchpad.
1. Lift the large piece of clear tape (1) that covers the touchpad and connector.
2. Disconnect the cable from the ZIF connector (2) on the touchpad.
3. Remove the three Phillips M1.6 × 2.5 screws (3) from the touchpad.
4. Lift the top of the touchpad (4) up, and then pull the touchpad (5) into the computer to remove it from
under the bracket.
Touchpad
35
