Table 4-3 Memory module specifications (continued)
Component Specification
Slots 2
Maximum memory 64 GB
Supported 2 Gbit, 4 Gbit, 8 Gbit, and 16 Gbit non-ECC memory technologies single-
sided and double-sided memory modules
NOTE: The system does not operate properly if you install unsupported memory modules. Memory
modules constructed with ×8 and ×16 DDR devices are supported; memory modules constructed with
×4 SDRAM are not supported.
Use this information to correctly populate SODIMM sockets:
There are two SODIMM sockets on the system board, with one socket per channel. The sockets are
labeled DIMM1 and DIMM3. The DIMM1 socket operates in memory channel B. The DIMM3 socket
operates in memory channel A.
The computer comes with double data rate 4 synchronous dynamic random access memory (DDR4-
SDRAM) small outline dual inline memory modules (SODIMMs).
IMPORTANT: You must disconnect the power cord and wait approximately 30 seconds for the power
to drain before adding or removing memory modules. Regardless of the power state, voltage is always
supplied to the memory modules as long as the computer is plugged into an active AC outlet. Adding or
removing memory modules while voltage is present can cause irreparable damage to the memory
modules or system board.
IMPORTANT: When handling a memory module, be careful not to touch any of the contacts. Doing so
can damage the module.
The memory module sockets have gold-plated metal contacts. When upgrading the memory, use
memory modules with gold-plated metal contacts to prevent corrosion, oxidation, or both, resulting
from having incompatible metals in contact with each other.
Static electricity can damage the electronic components of the computer or optional cards. Before
beginning these procedures, be sure that you are discharged of static electricity by briefly touching a
grounded metal object.
The system automatically operates in single-channel mode, dual-channel mode, or flex mode, depending
on how the SODIMMs are installed.
● The system operates in single-channel mode if the SODIMM sockets are populated in one channel
only.
● The system operates in a higher-performing dual-channel mode if the memory capacity of the
SODIMM in channel A is equal to the memory capacity of the SODIMM in channel B.
● The system operates in flex mode if the memory capacity of the SODIMM in channel A is not equal
to the memory capacity of the SODIMM in channel B. In flex mode, the channel populated with the
least amount of memory describes the total amount of memory assigned to dual channel and the
remainder is assigned to single channel. If one channel has more memory than the other, assign the
larger amount to channel A.
● In any mode, the maximum operational speed is determined by the slowest SODIMM in the system.
22
Chapter 4 Removal and replacement procedures
