HP Designjet 30/90/130 Printer series – Quick Reference Guide
62
English
Tell Me About the Front Panel
The front panel (or control panel) of the printer gives information about the status
of the printer, and also has three keys that let you control the actions of the
printer.
Note that the illustration below shows the HP Designjet 90&130 Printer series.
The numbers correspond to the following elements:
1. Display area
2. Cancel key: Cancels the current
operation.
3. OK key: Indicates to the printer:
• that you have now loaded paper in
the appropriate tray or feed, and the
printer may start printing;
• that you have corrected a problem—
for example, you have removed
jammed paper or replaced a failing
printhead—and that the printer should
continue with its activity—for
example, it should resume printing;
• that you want to cut the roll paper, if
you have a roll feed with roll paper
loaded.
4. Attention light: The Attention (yellow) light is on when the printer requires a
user action—for example, to close the top cover.
5. Power key: Turns the power on and off.
6. Power light: The Power (green) light is on when the printer is switched on.
The printer’s front panel has a display area that gives information about the
printer. The sets of icons in the lower two-thirds of the display refer respectively
to the Black, Cyan, Magenta, Yellow, Light Magenta and Light Cyan
components of the ink system.
