4–12 Maintenance and Service Guide

Removal and replacement procedures

RTC battery

Before removing the battery, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on,

and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and then

unplugging the AC adapter from the computer.

4. Remove the battery (“Battery” on page 4-7).

5. Remove the hard drive cover (see “Hard drive” on page 4-10).

Remove the RTC battery:

1. Use a sharp, non-conductive tool to release the clip 1 that secures the battery to the system board.

2. Lift the battery 2 out of the computer.

Reverse this procedure to install the RTC battery.

Description Spare part number

RTC battery 449729-001
