Removal and replacement procedures 4–24

Before removing the display assembly, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on,

and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and then

unplugging the AC adapter from the computer.

4. Remove the battery (see “Battery” on page 4-7).

5. Disconnect the wireless antenna cables from the WLAN module (see “WLAN module” on page 4-15).

6. Remove the keyboard (see “Keyboard” on page 4-17).

7. Remove the keyboard cover (see “Keyboard cover” on page 4-20).

Remove the display assembly:

1. Pull the antenna cables through the opening in the top cover 1 and disengage the cables from the clip 2 in the

routing channel leading to the display hinge.

2. Disconnect the display panel cable 3 from the system board and make sure that the cable is out of its routing

channel.

3. Disconnect the microphone cable 4 from the system board and release it from the clips that attach it to the

top cover.

4. Remove the caps lock LED 5 from its mounting clips on the top cover.
