Illustrated parts catalog 3–4

For use in Portugal 496771-131

For use in Russia 496771-251

For use in Saudi Arabia 496771-171

For use in South Korea 496771-AD1

For use in Spain 496771-071

For use in Switzerland 496771-111

For use in Thailand 496771-281

For use in Turkey 496771-141

For use in Taiwan 496771-AB1

For use in the United Kingdom 496771-031

For use in the United States 496771-001

For use in the United States (silver) 502958-001

(3) Keyboard cover 506848-001

(4) Power button board (includes power button board cable) 496830-001

(5) Top cover (includes TouchPad board) 506849-001

(6) TouchPad on/off button board (includes cables) 496832-001

(7) Fan/heat sink assembly for use with UMA systems (includes replacement thermal material) 489126-001

Fan/heat sink assembly for use with Discrete systems (includes replacement thermal

material)

489154-001

(8) TouchPad board bracket 489119-001

Plastics Kit (see Plastics Kit on page 3-9 for more Plastics Kit spare part information) 486621-001

(9a) Hard drive cover

(9b) Memory module compartment cover

(9c) WLAN module compartment cover

(10) USB board (does not include USB board cable) 486633-001

USB board cable (not illustrated, includes num lock LED) 496837-001

(11) System board

UMA system board, GM45 (includes built-in modem, Digital Media Slot, HDMI port, and

replacement thermal material)

485218-001

UMA system board, GM45 (includes built-in modem, Digital Media Slot, and replacement

thermal material)

494281-001

UMA system board, GL40 (includes built-in modem, Digital Media Slot, and replacement

thermal material)

494282-001

UMA system board, GL40 (includes built-in modem, Digital Media Slot, HDMI port, and

replacement thermal material)

485219-001

UMA system board, GL40 (for Presario CQ60 computer models only; includes built-in

modem and replacement thermal material)

501266-001

Discrete system board, PM45 (includes built-in modem, Digital Media Slot, HDMI port, and

replacement thermal material)

488338-001

Discrete system board, PM45 (includes built-in modem, Digital Media Slot, and replacement

thermal material)

494283-001

(Continued)

Item Description Spare Part Number
