External component identification 2–7

Left-side components

Right-side components

Item Component Function

1

Power connector Connects an AC adapter.

2

AC adapter light

■ On: The computer is connected to external power.

■ Off: The computer is not connected to external power.

3

External monitor port Connects an external VGA monitor or projector.

4

RJ-45 (network) jack Connects a network cable.

5

HDMI port (select models only) Connects an optional video or audio device, such as a high-definition

television, or any compatible digital or audio component.

6

USB port Connects an optional USB device.

7

Digital Media Slot (select models only) Supports the following optional digital card formats:

■ Memory Stick (MS)

■ Memory Stick Pro (MSP)

■ MultiMediaCard (MMC)

■ Secure Digital (SD) Memory Card

■ xD-Picture Card (XD)

■ xD-Picture Card (XD) Type H

■ xD-Picture Card (XD) Type M

8

Digital Media Slot light (select models only) On: The Digital Media Slot is in use.

Item Component Function

1

Optical drive Reads optical discs and, on select models, also writes to optical discs.

2

Optical drive light Blinking: The optical drive is being accessed.

3

USB ports (2) Connect optional USB devices.

4

RJ-11 (modem) jack (select models only) Connects a modem cable.

5

Security cable slot Attaches an optional security cable to the computer.

✎

The security cable is designed to act as a deterrent, but it may

not prevent the computer from being mishandled or stolen.
