32 Printing tasks ENWW
Loading optional tray 2
Optional tray 2 supports standard-size paper only. Paper includes
average-weight letterhead and prepunched paper. For additional
information about letterhead and prepunched paper, see “Printing on
letterhead or preprinted forms” on page 47.
CAUTION
Print special print media such as labels and grayscale transparencies
from tray 1 only. Printing special print media from optional tray 2 or
optional tray 3 can cause jams.
To load optional tray 2
1 Pull optional tray 2 out of the printer and remove any paper.
2 Move the side width guides to match the size of paper you are
loading.
3 Extend the rear of the tray until the arrow on the markings points to
the size you are loading.
4 Load the paper. If this is special paper such as letterhead, load it
with the side to be printed down and the top edge toward the front of
the tray.
Note
If you are manually duplexing, see “Printing on both sides (duplexing
manually)” on page 48 for loading instructions.
5 Make sure the stack of paper is flat in the tray at all four corners,
and keep it below the height tabs on the paper length guide in the
rear of the tray. Push down on the metal paper lift plate to lock it into
place.
6 Slide the tray back into the printer. If you set the rear of the tray to
one of the longer sizes, the back of the tray will protrude from the
back of the printer.
1
2
4
5
3
6
