1. Disconnect the cable from the ZIF connector on the fingerprint reader (1).
NOTE: To replace the fingerprint reader cable you must remove the system board.
2. Remove the Phillips M2.0 × 2.0 screw (2) from the fingerprint reader bracket, and then remove the
bracket (3).
3. Remove the fingerprint reader from the computer (4).
To install the fingerprint reader, reverse this procedure.
NOTE: When replacing the fingerprint reader bracket, insert it into the tab on the computer chassis at
an angle (1), press it down into place (2), and then replace the screw (3).
USB board
To remove the USB board, use this procedure and illustration.
Table 6-9
USB board description and part number
Description Spare part number
USB board N36076-001
USB board cable N36077-001
USB board 49
