10
REPLACING THE LAMP
1. Disconnect the oven from the power supply.
2. Unscrew the cover from the light, replace the bulb
and screw the cover back on the light.
3. Reconnect the oven to the power supply.
Please note: Use 25 W/230 V type G9, T300 °C halogen lamps.
The bulb used in the product is specically designed for
domestic appliances and is not suitable for general room
lighting within the home (EC Regulation 244/2009).
Light bulbs are available from our After-sales Service. - Do not
handle bulbs with your bare hands as your ngerprints could
damage them. Do not use the oven until the light cover has
been retted.
CLEANING THE DOOR GLASSES
1. After removing the door and resting it on a soft
surface with the handle downwards, simultaneously
press the two retaining clips and remove the upper
edge of the door by pulling it towards you.
2. Lift and firmly hold the inner glass with both
hands, remove it and place it on a soft surface before
cleaning it.
3. Refit the intermediate pane (marked with “1R”)
before refitting the inside pane: To position the panes
of glass correctly, make sure that the “R” mark can be
seen in the left-hand corner. First insert the long side
of the glass marked “R” into the support seats, then
lower it into position. Repeat this procedure for both
panes of glass.
4. Refit the upper edge: A click will indicate correct
positioning. Make sure the seal is secure before
refitting the door.
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE SOLUTION
The oven is not working.
Power cut.
Disconnection from the mains.
Check for the presence of mains electrical power and whether
the oven is connected to the electricity supply.
Turn off the oven and restart it to see if the fault persists.
The display shows the letter “F”
followed by a number or letter.
Oven failure.
Contact you nearest Client After-sales Service Centre and state
the number following the letter “F”.
The display is showing the
message “Hot” and the selected
function will not start.
Temperature too high.
Allow the oven to cool down before activating the function.
Select a different function.
400020013629
Policies, standard documentation and additional product information can be found by:
• Using the QR code in your appliance
• Visiting our website docs . hotpoint . eu
• Alternatively, contact our After-sales Service (See phone number in the warranty booklet). When contacting our After-
sales Service, please state the codes provided on your product's identication plate.
