EXP Settings

You can connect your own expression pedal to control various effects parameters.

To use an expression pedal to control parameters, please set EXP/CTRL jack function to EXP (see Controls section on ), page 24

assign parameters and turn the EXP switch on. If the current patch does not have any effect controllable by expression pedal or

the expression pedal switch is off, the pedal will not function.

From this menu, you can control the settings of or calibrate your external expression pedal.

There are three options within this menu: Target, Expression Range, and Calibrate.

You can press any quick access para in main menu to assign/set a quick access para as shown below:

Target

Under the Target option, you can set the pedal’s control target. You can set up a maximum of four effects parameters for the

built-in expression pedal to control.

Use SLOT/FUNC X (X standing for 1-4 controllable targets) to select a target slot/function. The available selections depend on

the modules/effects used in the current patch. If there is no module/effect, the available selections are OFF, Patch Tempo, Patch

Volume only.

If you select a slot, SLOT FX X will show the current effect you’re using in the center of the panel.

Use PARA X to select the parameter you want to assign to the expression pedal. The selectable parameters will vary with

different effects. Please refer to Effects List (on ) for more info. page 41

Touch the right or left arrows to flip through the panel.

You can also turn the expression pedal off by turning selecting OFF in the settings panel.

Expression Range

Under the Expression Range option, you can set the expression pedal expression range and sweep curve. There are four

adjustable targets to change these settings.

MIN X (X standing for 1-4 controllable targets) represents the lowest range value. This is the value the pedal will have when

pushed all the way up.

MAX X represents the highest range value, when the pedal is pushed all the way down.

CURVE X represents the curve line the pedal will follow when pushed from all the way up to all the way down.

The MIN and MAX range is the same as corresponding effect parameter, and the MIN value can be greater than the MAX value.

There are three CURVE types:

•Line follows a straight line

•Exp follows an exponential line from slow to fast

•Log follows a logarithmic line that changes as the pedal moves

Customizing Your Ampero II Stomp
