•Mode II

In this mode the split node will convert node input signal into dual mono signal and send it to both chain A and B. If the split

node is between slots with mixed mono/stereo effects (e.g. one stereo effect in the slot right before the split node, two mono

effects in slots right next to the split node on both chains for processing L/R outputs of the stereo effect), this mode is

recommended.

Use BALANCE A/B to set output signal content (L/R ratio of node input signal) from L50 ~Center~R50, default is set to

Center. Fine tune the parameter depending on your needs:

•BALANCE set to L50/R50 means only left/right channel of input signal will be sent to the slots next to split node

•BALANCE set to a value in between means a mixed signal will be sent to the slots next to split node; the value sets the

mixing ratio, set to Center means mixing ratio=1:1

Use LEVEL TO A/B to set output level to A/B chains from 0~100, default is set to 100.

Mixer Node

Select a split node and the parameters will come up as shown below:

Use A/B LEVEL to set input level from A/B chains. The ranges are all 0~100, defaults are all set to 100.

Use A/B PAN to set input signal stereo panning from A/B chains. The ranges are all L50~Center~R50, defaults are all set to

Center.

When you mix A/B chain signals, output may sound very sharp/thin/weak/muddy, even left and right outputs are L/R not

balanced, this may be caused by signal phase issue. If mixed output sounds abnormal, you can set B POLARITY to reverse

chain B signal phase and see if the problem solved or not. B POLARITY is set to Normal by default. Sometimes reversing chain

B’s phase may surprise you.

Use MASTER to set output level of mixer node. The range is 0~100, default is set to 50.

Turn on MASTER SUM switch to sum mixer node output to a dual mono output. Default is set to Off.

Please note:

Setting split node to Mode II only will NOT lead to a result like “left output is a kind and right is another”, since extra

output/mixer nodes settings are needed.

Please note:

1. When using stereo effects, in some cases, turning on MASTER SUM may lead to an abnormal output or even no output,

this may be caused by L/R phase cancellation.

2. Please adjust A/B LEVEL and MASTER carefully to prevent signal clipping.

Customizing Your Ampero II Stomp
