18
7) Remove the shelves from the door section, then remove the pilasters and place and
secure them in the new location (current drawer location). See Fig. 21. Note: Other than
in a center location, outer pilasters mount on the side wall not the rear wall.
8) Place and secure the pilaster ller screws removed in step 6 into the new drawer
location (current door location).
Shelves
Pilasters
Pilasters
9) Remove the drawer cartridge frame rear ller screws from the new location (current
door location). Place the drawer cartridge frame ller screws in the new door location
and tighten. Replace the shelves. See Fig. 22.
Fig. 21
Rear Filler
Screws
Shelves
Rear Filler
Screws
Fig. 22
