2. Adjusting the Temperature Setpoint

The temperature setpoint is used to adjust the amount of cooling for the cabinet.

Note: The temperature differential for the compressor to turn on or off is:

Refrigerator: ±2.7°F (±1.5°C) of the temperature setpoint.

Freezer: ±2.2°F (±1.2°C) of the temperature setpoint.

For example, a refrigerator temperature setpoint of 34°F (1.1°C), the compressor turns on

at 36.7°F (2.6°C) and the compressor turns off at 31.3°F (-0.4°C). If necessary, adjust the

temperature setpoint temperature as follows:

a) To change the temperature setpoint, press the down button briey and then release.

SP1 ashes for a few seconds, then the current temperature setpoint appears. Press

the up or down button until the desired value is displayed. After 10 seconds or the

"P" button is pressed, the display returns to the current cabinet temperature and the

temperature setpoint is saved. NOTICE! Do not adjust the temperature setpoint

more than 2°F (1°C) at a time. Allow the temperature to stabilize for a minimum

of 8 hours before making further temperature setpoint adjustments.

Model Temperature Setpoint Range Factory Default

Temperature Setting

Refrigerator 28°F to 45°F (-2.2°C to 7.2°C) 36°F (2.2°C)

Freezer -12°F to 10°F (-24.4°C to -12.2°C) 2.0°F (-16.7°C)

3. Cabinet Temperature Display Scale (°F or °C)

There are 4 temperature display settings from which to choose.

The factory temperature display default is F0 for °F whole number.

For a whole number temperature display scale value, select F0 or C0.

For a temperature display scale value to one decimal point, select F1 or C1.

Display Scale Temperature Display Style

F0 - Factory Default 36°F

C0 2°C

F1 36.0°F

C1 2.2°C

To change the temperature display scale value, follow the steps below:

1) Press the "U" and "P" buttons together for 5 seconds. i.uP is displayed.

2) Press the "P" button. The current display setting (F0, F1, C0, or C1) and I.uP start

ashing.

3) Press the up or down button until the desired temperature display style is displayed.

4) Press the "P" button to save the selection. I.uP is displayed. To return to normal display

mode, press and hold the "U" button for 5 sec. Display returns to normal display mode.

If no other button is pressed after pressing the "P" button, 25 sec. later, display returns

to normal display mode.

Note: If no selection is saved within 30 seconds, the display returns to normal mode

and the temperature display scale remains unchanged.
