7
I. Specications
A. Electrical and Refrigerant Data
The rating label and nameplate provide electrical and refrigerant data. The rating label
can be seen by removing the front panel. The nameplate is located on the rear panel. For
certication marks, see the nameplate.
We reserve the right to make changes in specications and design without prior notice.
1. KM-1301S_J/3
Single Phase
Model Number KM-1301SAJ KM-1301SWJ KM-1301SRJ
AC Supply Voltage 208-230/60/1 208-230/60/1 208-230/60/1
Compressor 230V 10.0RLA 61LRA 230V 8.8RLA 56LRA 230V 9.3RLA 56LRA
Pump 120V 1.2FLA 60W 120V 1.2FLA 60W 120V 1.2FLA 60W
Fan 115V 1.0FLA 1/15HP --- --- --- 120V 3A MAX (Fans in URC)
Other 115V 0.3A 115V 0.3A 115V 0.3A
Maximum Fuse Size 20 AMPS 20 AMPS 20 AMPS
Max. HACR Breaker
(USA Only)
20 AMPS 20 AMPS 20 AMPS
Max. Circuit Breaker
(Canada Only)
20 AMPS 20 AMPS 20 AMPS
Minimum Circuit
Ampacity
20 AMPS 20 AMPS 20 AMPS
Design Pressure HI-467PSI LO-230PSI HI-427PSI LO-230PSI HI-467PSI LO-230PSI
Refrigerant 404A 4 LB. 3 OZ. 404A 2 LB. 2.4 OZ. 404A
Total Refrigerant Charge with
Hoshizaki Remote Condenser
Unit URC-14F: 10 LB. 5.8 OZ.
Three Phase
Model Number KM-1301SAJ3 KM-1301SWJ3 KM-1301SRJ3
AC Supply Voltage 208-230/60/3 208-230/60/3 208-230/60/3
Compressor 230V 7.1RLA 55LRA 230V 6.5RLA 51LRA 230V 6.2RLA 51LRA
Pump 120V 1.2FLA 60W 120V 1.2FLA 60W 120V 1.2FLA 60W
Fan 115V 1.0FLA 1/15HP --- --- --- 120V 3A MAX (Fans in URC)
Other 115V 0.3A 115V 0.3A 115V 0.3A
Maximum Fuse Size 20 AMPS 20 AMPS 20 AMPS
Max. HACR Breaker
(USA Only)
20 AMPS 20 AMPS 20 AMPS
Max. Circuit Breaker
(Canada Only)
20 AMPS 20 AMPS 20 AMPS
Minimum Circuit
Ampacity
20 AMPS 20 AMPS 20 AMPS
Design Pressure HI-467PSI LO-230PSI HI-427PSI LO-230PSI HI-467PSI LO-230PSI
Refrigerant 404A 4 LB. 3 OZ. 404A 2 LB. 2.4 OZ. 404A
Total Refrigerant Charge with
Hoshizaki Remote Condenser
Unit URC-14F: 10 LB. 5.8 OZ.
