36
I. Startup
WARNING
• All parts are factory-adjusted. Improper adjustments may adversely affect safety,
performance, component life, and warranty coverage.
• Make sure the icemaker has been installed as outlined in this manual and that the
water supply is on.
• Improper adjustment may adversely affect safety, performance, component life,
and warranty coverage.
NOTICE
• If the icemaker is turned off, wait for at least 3 minutes before restarting the
icemaker to prevent damage to the compressor.
• To prevent damage to the water pump seal, do not leave the control switch in the
"PUMP" position for extended periods when the water tank is empty.
• At startup, conrm that all internal and external connections are free of leaks.
Additional Notice for Remote Models
• The icemaker must have power for a minimum of 4hours prior to startup to
prevent compressor damage.
1) If not already removed, remove the front panel, then open the water supply line shut-off
valve(s).
2) Move the control switch on the control box to the "ICE" position.
3) Replace the front panel in its correct position.
4) Turn on the power supply, and allow the icemaker to operate for a total of 10 minutes.
5) Turn off the power supply, then remove the front panel.
6) Remove the insulation panel. Remove the drain plug located on the lower front part of
the ice chute. See Fig. 16. Allow the water tank to drain.
Drain Plug
Ice Chute
Float Switch Assembly
Cleaning Valve
Fig. 16
7) Replace the drain plug, insulation panel, and front panel in their correct positions.
Be careful not to cross thread the drain plug.
