36
J. Startup
1. Bin Control Setting
An ultrasonic sensor is used as the bin control to control the level of ice in the dispenser
unit/ice storage bin. The bin control setting must be set to match the application to avoid
possible icemaker movement, water leakage, or ice overow.
WARNING
• Improper adjustment may adversely affect safety, performance, component life,
and warranty coverage.
• On dispenser unit applications, do not increase ice level above the recommended
setting listed below. Higher ice levels could result in icemaker movement, water
leakage, or ice overow.
NOTICE
Do not allow top kits or top kit risers (if applicable) to interfere with the bin control
lens sensing area or the icemaker will not operate properly.
1) Move the power switch to the "OFF" position. Make sure the power supply is off to
the icemaker and condensing unit. Remove the front panel to access the control box
assembly. See Fig. 15. Remove the control box cover to access the control board.
See Fig. 16.
2) Conrm the correct control board bin control setting required for your application and
adjust according to the following tables. See Fig. 17 and Fig. 18.
Power
Switch
Control
Box Cover
Fig. 15 Fig. 16
Control Box
Assembly
Control
Board
Ultrasonic
Bin Control
