13EN
WATER CONDENSATION DRAINAGE
When there is excess water condensation inside the unit, the air conditioner stops running and
shows a warning light (the WATER FULL indicator
illuminates with a red light). This indicates that
the water condensation needs to be drained using the following procedures:
Unplug the unit from power source.
Place a drain pan under the lower rubber drain plug.
See diagram.
Remove the drain plug.
Water will drain out and collect in the shallow pan.
After the water is drained, reinstall the drain plug.
You can now turn on the unit.
1.
2.
3.
4.
5.
6.
Water may need to be drained in high humidity areas.
Manual Draining in Cooling, Dehumidifying Modes
IMPORTANT: Do not connect the drain Tube for continuous drainage while the unit is in cooling
mode, as it reduces efficiency. Use continuous drainage only in Dehumidifier mode. Ensure the hose
is short and has enough height difference for proper drainage.
IMPORTANT: The water cannot be drained using the continuous drain option in heating* mode. In
Heating mode, the water tank fills faster and may need frequent emptying in humid rooms. Use in
rooms with 50% or lower humidity, and avoid moisture-generating appliances like humidifiers or
kettles.
IMPORTANT: Only drain the water condensation when the unit is switch off unless continuous
draining in dehumidifier mode.
Remove the upper drain plug.
Some residual water may spill so please have a pan to
collect the water.
Connect the drain tube to the Upper Continuous Drain
Outlet. See diagram.
The water can be continuously drained through the
drain tube into a floor drain or bucket.
When draining is complete, remove the tube and replace
the drain drain plug cap.
You can now turn on the unit.
1.
2.
3.
4.
5.
Continuous Draining in Dehumidifier Mode
Drain Tube (included):
Dia. 15mm
Length: 1m
Upper Rubber
Drain Plug
While using the unit in dehumidifier mode, continuous drainage is recommended.
Lower
Rubber
Drain Plug
Drain Pan
(not included)
*Applicable for models with heating feature only.
