16
General system information
5 General system information
This device is part of the HomematicIP
smart home system and works with the
HomematicIP protocol. All devices of
the system can be configured com-
fortably and individually with the user
interface of the Central Control Unit
CCU3 or flexibly via the HomematicIP
smartphone app in connection with
the HomematicIP cloud. All available
functions provided by the system in
combination with other components
are described in the HomematicIP
Wired Installation Guide. All current
technical documents and updates are
provided at www.homematic-ip.com.
6 Start-up
6.1 Installation instructions
Since the bus is powered by the
Homematic IP Wired Access Point
(HmIPW-DRAP), you must first
set-up a Homematic IP Wired
Access Point (HmIPW-DRAP) to
enable power supply for the de-
vice.
Before installation, please note
the device number (SGTIN) la-
belled on the device as well as the
exact application purpose in order
to make later allocation easier.
You can also find the device num-
ber on the QR code sticker sup-
plied.
Please note the insulation strip-
ping length of the conductor to
be connected, indicated on the
device.
Please observe the hazard infor-
mation in section (see „2 Informa-
tion about this manual“ on page
14).
Please note! Only to be installed
by persons with the relevant elec-
tro-technical knowledge and
experience!*
Incorrect installation can endanger
• your own life,
• and the lives of other users of the
electrical system.
Incorrect installation also means that
you are running the risk of serious
damage to property, e.g. because of
a fire. You may be personally liable
in the event of injuries or damage to
property.
Consult an electrician!
*Specialist knowledge required for ins-
tallation:
The following specialist knowledge is
particularly important during installati-
on:
• The “5 safety rules” to be used:
Disconnect from mains; Safeguard
from switching on again; Check
that system is deenergised; Earth
and short circuit; Cover or cordon
o neighbouring live parts;
• Select suitable tool, measuring
equipment and, if necessary, per-
sonal safety equipment;
• Evaluation of measuring results;
• Selection of electrical installation
material for safeguarding shut-o
conditions;
