26

General system information

Display overview:

Setpoint/actual temperature

Humidity

Open window symbol

Battery symbol

Radio transmission

Boost function

Manual operation*

Automatic mode*

Holiday mode*

Heating

Cooling

Operating lock*

Setpoint temperature

Overview of heating phases

Time and date*

Oset temperature*

Programming a heating

profile*

Days of the week

* (see „7 Configuration menu“ on page

32)

Figure 2

5 General system information

This device is part of the climate con-

trol solution of HomematicIP and

works with the HomematicIP radio

protocol. All devices of the climate

control solution can be configured

comfortably and individually with a

smartphone via the HomematicIP app.

The available functions provided by the

HomematicIP system in combination

with other components are described

in the HomematicIP User Guide. All

current technical documents and up-

dates are provided at

www.homematic-ip.com.

6 Start-up

Please read this entire section

before starting the pairing proce-

dure.

For more information on teaching

and setting up the wall thermostat

using a CCU3, please refer to the

WebUI manual on our homepage

at www.homematic-ip.com.

The wall thermostat must first be

added in order to be able to com-

municate with other devices in your

system. To control your heating, you

can teach the wall thermostat to the

HomematicIP Access Point as de-

scribed in (see „6.2 Pairing to the

HomematicIP Access Point“ on page

28).

6.1 Direct pairing

You can connect the

HomematicIP Wall Thermostat to

a HomematicIP Floor Heating

Actuator (HmIP-FALx-Cx,

HmIP-FALMOT-Cx), a

HomematicIP Radiator Thermos-

tat – basic (HmIP-eTRV-B/

HmIP-eTRV-B-2/ HmIP-eTRV-B-A)

or a HomematicIP Window- and

Door Contact with magnet

(HmIP-SWDM/HmIP-SWDM-2).

Please make sure you maintain a

distance of at least 50cm bet-

ween the devices.
