OPERATION
HOLZMANN MASCHINEN GmbH www.holzmann-maschinen.at 16
RWH 150XLIFT
14 OPERATION
Please check the product contents immediately after receipt for any eventual transport damage or
missing parts. Claims from transport damage or missing parts must be placed immediately after
initial machine receipt and unpacking before putting the machine into operation. Please
understand that later claims cannot be accepted anymore.
14.1 Assembly
14.1.1 Transport security
Press the handle socket down and then pull the retaining clip out
14.1.2 Handle
Remove the fixing screw from the handle socket and put the handle into handle socket hole,
engaging the U-joint of the release valve .Ensure the handle is seated completely into the socket
then tighten the fixing screw. Make sure the handle is secured to the jack by the fixing screw.
14.2 Lifting
Turn the release screw counter clockwise to lower the jack. Once the jack is fully lowered,
turn the release screw firmly clockwise to close it.
Carefully position the saddle of the jack under the vehicle’s lifting point. (See vehicle
manufacturer’s owner’s manual for location of frame lifting point.)
Pump the handle until the top of the jack’s saddle has nearly reached the vehicle lifting
point. Position the saddle directly under the vehicle’s lifting point.
Pump the handle or foot pedal until the top of the jack’s saddle has nearly reached the
vehicle lifting point.
To lift the vehicle, pump the handle or the foot pedal of the jack. Use smooth, full strokes.
Once the vehicle is raised, slide a jack stand of appropriate capacity (not included) under a
proper lifting point referred to in the vehicle owner’s manual. Always use two jack stands,
position them at the same point on each side of the vehicle
AT T E N T I ON
Never work on, under or around a load supported only by a jack.
While working observe the saddle and the vehicle’s lifting point of the
vehicle to grant any movements.
14.3 Lowering
Carefully remove all tools, parts, etc. from under the vehicle.
Position the saddle under the lifting point. Turn the release screw firmly clockwise and
raise load high enough to clear the jack stands, then carefully remove jack stands.
Slowly turn the release screw counterclockwise (never more than 1/2 turn) to lower the
vehicle onto the ground.
Lower the Jack completely
If the lifting arm does lower completely, there might be air in the system.
Before using the floor jack next time, carry out bleeding process.
