MAINTENANCE
HOLZMANN MASCHINEN GmbH www.holzmann-maschinen.at 84
ED1000KDIG | ED1500KDIG
Apron (3)
The oil must reach the mark in the oil sight glass. To change the oil, drain the oil by removing the
drain plug (D). To refill the oil use the refill opening (F). Check the oil level regularly.
First oil change (running-in oil) after 100 operating hours, then change the oil once a year or after
1000 operating hours.
20.1.4 Other lubrication points
Gear wheels
Lubricate the gears with a heavy, non-spinning grease. Make sure that no grease gets onto belt
pulleys or belts!
Grease nipples and lubricators
Lubricate or fill grease nipples or oilers on the lead
screw and feed rod, on the tailstock as well as on the
face and top slides with machine oil weekly.
20.1.5 Checking and cleaning the coolant system
NOTICE
Coolants are toxic and must not be released into the environment! Follow
the manufacturer's instructions and contact your local authority for
information on proper disposal if necessary.
Checking the coolant system
1. Open the cover to the pump
chamber/coolant tank.
2. Check the coolant level in the tank.
The liquid should be about one
centimetre below the top edge of the
tank.
3. Check the level of the metal chips in the
first chamber. When the chips have
reached 3⁄4 the height of the partition,
remove the chips.
4. Check the quality of the coolant
according to the manufacturer's
instructions and replace it as
recommended.
