Spec-00212 I

FREESTAND CABINETS PROLINE™ AccEssORIEs

PH 763.422.2661 • FAX 763.422.2588 • HOFFMANONLINE.COMEQUIPMENT PROTECTION SOLUTIONS NETWORKING 4

CASTER KIT

A set of four casters (two locking,

two non-locking) that mount directly

to the bottom of a PROLINE™

frame, 0-mm, or 100-mm Solid

Base or a Console. (Do not use on

plinth bases.) Casters elevate the

enclosure 110 mm (4.33 in.) when

installed. Caster frames are plated

steel with ball-bearing pivots.

Caster wheels are made of a black

polyamide material. Kit includes

M12 mounting hardware.

Order separately.

Casters Maximum Load: 1000 lb.

(453 kg)

Exercise care when using casters

to move the cabinet. Avoid tipping

and damage to the cabinet and

its contents by slowly moving

the cabinet on its casters across

smooth, flat flooring. Avoid:

• large cracks

• floor displacement

• seams

• gravel

• any other obstruction

Never use casters while

transporting a cabinet by truck on

roadways.

Contact Hoffman if further

information is needed.

BulletIn: p20

Catalog Number Description

PC1M12 Set of 4 Casters

SCREW PACKAGES

Screw Packages are for mounting

rack panels and equipment to rack

angles.

BulletIn: A80, DAccY, X20

Catalog Number

Color Description

Pkg. Qty.

ES1224 Silver 12-24 x 5/8 in. combo head 20

ES1224250 Silver 12-24 x 5/8 in. combo head 250

ES1224B Black 12-24 x 5/8in. combo head 20

ES1224B250 Black 12-24 x 5/8 in. combo head 250

ASM5 Silver M5 x 20 mm Combo Head 20

ASM6 Silver M6 x 16 mm combo head 20

ASM5T Silver M5 x 12 mm thread-forming Phillips hex head screws 20

ASM6250 Silver M6 x 16 mm combo head 250

AS1032 Silver 10-32 x 5/8 in. combo head 20

AS1032250 Silver 10-32 x 5/8 in. combo head 250

AS1032B Black 10-32 x 5/8 in. combo head 20

Use ASM5T on PROLINE

™

frame or Net Series extruded holes.

CAGE NUT PACKAGE

Cage Nut Packages are for use with

square-hole rack angles. Cage nuts

are plated steel.

BulletIn: DAccY, p20

Catalog Number

Color Description

Pkg. Qty.

PM5CN Silver M5 cage nut 20

PM6CN Silver M6 cage nut 20

PM6CN250 Silver M6 cage nut 250

P1032CN Silver 10-32 cage nut 20

P1032CN250 Silver 10-32 cage nut 250

P1224CN Silver 12-24 cage nut 20

P1224CN250 Silver 12-24 cage nut 250
