WARNING: READ ALL INSTRUCTIONS BEFORE USING ANY FITNESS EQUIPMENT. WE ASSUME NO RESPONSIBILITY
FOR PERSONAL INJURY OR PROPERTY DAMAGE CAUSED BY OR THROUGH THE USE OF THIS PRODUCT
SPECIFICATIONS
Weight – 24,5 kg
Flywheel – 9 kg
Dimensions – 93 x 54,5 x 128,5 cm
Maximum weight of user – 120 kg
MAINTENANCE
Your unit has been carefully designed to require minimum maintenance. To ensure this, we recommend that you do the following:
Keep your unit clean by wiping sweat, dust or other residue off with a soft, clean cloth after each use
Always make sure that the bands are secure and show no signs of wear
Regularly check the tightness of nuts and bolts
SADDLE ADJUSTMENT
Loosen seat post screw. Set height according to growth. Tighten up screw. Do not take out seat post from the main frame.
TENSION ADJUSTMENT
To reduce tension turn control into sign ”-” direction, to increase tension turn control into sign “+” direction.
BREAKING
Stop to pedal when you want stop the item. Magnetic bike M9239V HMS not acquire breaking system or emergency break.
PARTS LIST AND TOOLS
Description
Qty
No.
Description
Qty
1
Rear stabilizer
1
39
Magnetic spring
1
2
2
40
Pedal(Left & Right)
2
3
4
41
8-section tension control
1
4
Main frame
1
42
M8×16 Bolt
4
5
1
43
6
Front cover
1
44
Crosshead bolt M5×35
1
7
Handlebar support
1
45
Pole pulg
2
8
Handlebar
1
46
Crosshead self bolt ST2.9×8
2
9
Φ25 Ball plug
2
47
Crosshead self bolt ST4.2×16
8
10
Foam grip
2
48
Round M8×40 Bolt
1
11
Computer
1
49
Half round bolt M8*20
4
12
Sensor
2
50
Spring spacer
8
13
Front plastic cover
1 51
Crosshead self bolt ST4.2×20
9
14
Seat cushion tube cover
1 52
Cap nut M6
3
15
Φ6 Flat washer
3 53
Extra-thin small hexagon nut
3
Rotating foot-cover
Fixed foot-cover
Front stabilizer tube
