- 9 -
• English
Operating and Installation Instructions 1.0SI SERIES P10
3 Application Guide
3.1 Basic use of P10 loudspeakers
The modular extendable P10 loudspeakers are suitable for installations in acoustically dicult
conditions. This can apply to critical room acoustic conditions with long reverberation times and flutter
echoes as well as to high ambient noise levels. Due to their technical characteristics, P10 loudspeakers
are particularly suitable for coping with a combination of the above-mentioned problems (dicult room
acoustics with simultaneously high environmental sound levels).
The more P10 loudspeakers are operated together in a line arrangement, the narrower their vertical
dispersion behaviour becomes. Likewise, the maximum achievable sound pressure level increases.
Optimal results are achieved in most practical applications when the loudspeakers are placed just above
ear level and "grazing" the audience areas.
As a matter of principle, we recommend carrying out acoustic simulations during the planning phase
using suitable software (EASE 4.4, EASE Focus 3). Only in this way can the necessary quantities and the
optimal positioning/alignment of the P10 loudspeakers be planned with good certainty.
Basically, the P10 speakers are designed to form lines vertically.
Attention! An arrangement of P10 loudspeakers in the horizontal plane is not intended and
is generally not recommended. The positioning of several P10 loudspeakers directly next to
each other is also not permitted.
For justified exceptions to these rules, it is essential to seek the assistance of the manufacturer and/or
a professional acoustician with practical experience in sound reinforcement.
3.2 Permitted areas of use and environmental conditions
All P10 loudspeakers are certified according to EN 54-24:2008 for use in voice alarm systems in case of
fire. In addition, the P10 loudspeakers are also recommended for use in public address systems that are
not planned for alarm purposes in the event of fire, such as electroacoustic emergency warning systems
in accordance with EN 50849. The latter standard assumes that EN 54-24 products are fundamentally
suitable for their area of specification.
Irrespective of the above-mentioned normative specifications, the P10 loudspeakers are of course
suitable for all other forms of public address systems where high audio quality with spatially adapted
loudspeakers is required.
Basically, all P10 loudspeakers are specified with protection class IP 66 according to EN 60529. The
conformity was approved by an independent institute (TÜV SÜD Product Service GmbH). Therefore,
installation in unroofed and unprotected outdoor areas is permissible. The P10 loudspeakers may be
exposed to strong dust/dirt loads as well as strong loads from water.
All P10 loudspeakers are also certified as ball impact resistant according to DIN 18032-3. This has been
tested and confirmed by an independent institute (Materials Testing Institute at the University of
Stuttgart). Therefore, the P10s may be installed in sports facilities with the loads typical there.
3 Application Guide
