- 26 -
• English
Operating and Installation Instructions 1.0SI SERIES P10
5.6 Pole Support
86
59
38,7
38,7
1.) The pole support must be connected to the speaker enclosure
using the M5 pan-head screws provided in the enclosure.
2.) If desired, the loudspeaker line can be extended by additional
P10s. In this case, the connector plates must be used (see 5.2).
3.) Suitable steel connectors or clamps can be used to fasten
the speakers. These are not included in the HK Audio scope
of delivery and are not oered due to application-specific
requirements.
4.) In practice, clamps from the supplier Würth have proven
themselves, e.g.: "Würth hose clamp A4", clamping range
50-70 mm, article number at Würth: 0538 50 70.
Note: If clamps of poor quality are used, such as those
with a load-bearing capacity that is not appropriate for
the application or those with a rapidly decreasing clamping
force, the ball impact safety certificate according to
DIN 18032-3 is invalid. So please always ensure correct
assembly based on these instructions.
pos. description qty.
1 Pole support 2
2 M5 pan-head screw 8
5 Mounting instructions for mechanical accessories
