English
16
(2) Use the auxiliary hexagonal wrench or small screwdriver to pull up the edge of the
spring that is holding down the carbon brush. Remove the edge of the spring toward
the outside of the brush holder.
(3) Remove the end of the pig-tail on the carbon brush from the terminal section of
brush holder and then remove the carbon brush form the brush holder.
<Assembly>
(1) Insert the end of the pig-tail of the carbon brush in the terminal section of brush
holder.
(2) Insert the carbon brush in the brush holder.
(3) Use the auxiliary hexagonal wrench or small screwdriver to return the edge of the
spring to the head of the carbon brush.
(4) Mount the tail cover and tighten the D4 tapping screw.
5. Service and repairs
All quality power tools will eventually require servicing or replacement of parts because
of wear from normal use. To assure that only authorized replacement parts will be
used, all service and repairs must be performed by a HITACHI AUTHORIZED SERVICE
CENTER, ONLY.
6. Service parts list
CAUTION:
● Repair, modification and inspection of Hitachi Power Tools must be carried out by a
Hitachi Authorized Service Center.
This Parts List will be helpful if presented with the tool to the Hitachi Authorized
Service Center when requesting repair or other maintenance.
In the operation and maintenance of power tools, the safety regulations and standards
prescribed in each country must be observed.
MODIFICATIONS: Hitachi Power Tools are constantly being improved and modified to
incorporate the latest technological advancements.
Accordingly, some parts may be changed without prior notice.
