Installing your new appliance
15
Door Removal (if needed)
In case your home access door is too
narrow for the refrigerator to pass
through, remove the doors.
Tools you will need(Not provided):
Allen Wrench
(5/32'', 4mm)
Philips Screwdriver
Wrench
(5/16'', 8mm)
1. With the door closed, remove the 3
screws holding the top covers (1) with
philips(+) screwdriver, and then remove
the top cover.
1
Disconnect power before
removing doors.
Reconnect ground wire before
operating.
Failure to do so could result in
death or electric shock.
Warning
3. Remove the screws(3) fixed on the
upper hinges with a wrench(5/16'', 8mm)
and the ground screw(4) attached to
the hinge with phillips(+) screwdriver.
Remove the upper left and right door
hinges(5).
2. To remove the wire connector, press
the top of the connector(2) and
separate it from the other one.
2
3
4
5
