Installing your new appliance
Door Removal (if needed)
In case your home access door is too
narrow for the refrigerator to pass
through, remove the doors.
Tools you will need(Not provided):
Allen Wrench (5/32'', 4mm)
Philips Screwdriver
Wrench (5/16'', 8mm)
3. Remove the screws(6) fixed on the
upper hinges with a wrench(5/16'', 8mm)
and the ground screw(7) attached to
the hinge with Phillips(+) screwdriver.
Remove the upper left and right door
hinges(8).
2. Separate the two connectors on the
left side door. To remove the wire
connector, press the top of the
connector(2) and separate it from the
other one. To remove the water coupler
from the hinge, twist and pull the clip(3)
from the coupler. Remove the water
line(4) while pressing the movable
part(5) of the water line coupler.
1. With the door closed, remove the 4
screws holding the top covers (1) with
Philips(+) screwdriver, and then remove
the top cover.
1
6
7
8
15
Disconnect power before
removing doors.
Reconnect ground wire before
operating.
Failure to do so could result in
death or electric shock.
Warning
2
5
3
4
