Stone countertop
1. Countertop
2. Appliance
3. Slot
Ceramic, wooden, or glass countertop
1. Countertop
2. Appliance
3. Slot
4. Wooden frame, thickness 16 mm
Given the margin of error (tolerance) for the glass ceramic plate of the appliance, and the cut-out in
the countertop, the slot is adjustable (min. 2mm).
Install the wooden frame 5 mm below the upper edge of the countertop (see figure).
WARNING!
The service department shall only be responsible for repairing and servicing the cooking hob.
Consult your specialized kitchen equipment dealer regarding re-installing the flush-mount
cooking hob.
Electrical connection
• This appliance must be earthed.
• The electrical connection must comply with national and local regulations.
• The cooking hob has to be hard-wired directly to the power mains.
• Prior to installation, ensure that the local distribution conditions (voltage and frequency) and the
adjustment of the appliance are compatible.
• The voltage, frequency, power and the country for which the appliance has been designed are
shown on the appliance rating plate.
• For class I appliances, check that your home’s electrical system provides proper earthing.
• The wall plug socket and plug should always be accessible.
• If a stationary appliance is not fitted with a supply cord and a plug, or with other means for
disconnection from the supply mains having a contact separation in all poles that provide full
disconnection under overvoltage category III conditions, the means for disconnection must be
incorporated in the fixed wiring in accordance with the wiring rules. This is also applicable for
appliances with a supply cord and plug when the plug is not accessible after installing the appliance.
Using an omnipolar switch with a contact separation of at least 3 mm fitted in the fixed wiring will
fulfil this requirement.
• The power cord must hang freely and should not be fed through a drawer.
• Use an approved cable with the correct cable diameters appropriate for the connection. The cable
casing should be able to withstand at least 65 °C and therefore preferably be of type H05VV-F.
• Before connecting the appliance, make sure the voltage indicated on the rating plate conforms
to the voltage in your power mains.
• The connection should be adjusted to the current and fuses.
• The appliance should not be connected to the mains via a multi-plug adapter or extension cable,
as the safe use of the equipment cannot be guaranteed.
13
