NOTE
Hang the rear grille on the front case of the motor; rotate the grille lock nut clockwise to lock
the rear grille.
Misalignment will lead to unstable installation and the logo on the front grille will be skewed.
47
7
4
7
Rotate clockwise and
fix the rear grille
Align the convex
point on the front case of the motor to the round
hole of the rear grille
4 Install the blade
5
6
Fix the blade on the motor shaft with the blade lock nut.
Convex to
concave
Press the
blade inwardly
Rotate
counter-
clockwise
Rotate the blade
counterclockwise with
the right hand to lock the
blade lock nut
5
6
Fix the blade
with left hand
Tighten
6
