Remove all packing material and accessories. Examine the
oven for any damage such as dents or broken door. Do
not install if oven is damaged.
Cabinet: Remove any protective lm found on the
microwave oven cabinet surface. Do not remove the
waveguide cover that is attached to the oven cavity to
protect the magnetron.
1. Select a level surface that provide enough open space
for the intake and/or outlet vents.
20cm
30cm
20cm
min85cm
0cm
-
The minimum installation height is 85cm.
-
The rear surface of appliance shall be placed against
a wall. Leave a minimum clearance of 30cm above
the oven. A minimum clearance of 20cm is required
between the oven and any adjacent walls.
-
Do not remove the legs from the bottom of the oven.
-
Blocking the intake and/or outlet openings can
damage the oven.
-
Place the oven as far away from radios and TV as
possible. Operation of microwave oven may cause
interference to your radio or TV reception.
2. Plug your oven into a standard household outlet. Be
sure the voltage and the frequency is the same as the
voltage and the frequency on the rating label.
WARNING: Do not install oven over a range cooktop or
other heat-producing appliance. If installed near or over a
heat source, the oven could be damaged and the warranty
would be void.
The accessible surface may be hot during operation.
MOUNTING THE MICROWAVE OVEN
INSTALLATION
Countertop Installation
18
