10
Contents of conversion set
• Nozzles for burners and (it applicable) by-pass screws for gas taps.
• Data label with the modified gas specifications and setting.
Tools needed:
T1 Socket! spanner (7 mm)
T2 Screwdriver fiat blade
(4 mm)
T3 Nose pliers
T4 Open-end spanner (7 mm)
T5 Leak test spray.
Please note, disconnect the appliance from the power
supply.
Prevent damage of the worktop. Lay down parts of the
appliance on a protected NOTE! base.
For converting to a different type of gas, the nozzles must be
changed. The values are also marked on the nozzle.
1. Remove pan supports, burner heads, crowns, and covers (see
pictures A1 and A2). Pull off the control knobs vertically.
2. Use the socket (T1) or open-end spanner (T4) to remove the
old nozzles and place the new nozzles inside the burner cups
(see pictures A1 and A2).
3.3. Regulating the burner minimum setting
When switching from one type of gas to another, the minimum
flow rate must also be corrected. The flame should not go out
even when passing suddenly from maximum to minimum flame. To
regulate the flame, follow the instructions below:
