Installing the P-Clip
Please place the TV on a horizontally stable surface, and then use P-Clip to connect the TV
and the wall or pillar. (Marked in the illustration below.)
1.
Fix part of P-Clip to the screw hole on the back of TV set with a M6×12 screw.
2. Select a suitable hole of P-Clip on part and fix it to the wall or pillar with a ST4×25
screw.
Select a suitable
screw hole based on
the actual situation.
Screw:
M6×12
P-Clip
65" 75"
screw hole
For 43"/50"/55"/65"/75"
screw hole
50"/55"
screw hole
43"
screw hole
NOTE
Insecure installation may cause the tilt or falling of the product, and further lead to per-
sonal injuries or product damages. If the method above can not fix the product, please
consult the manufacturers.
P-clip and corresponding screws may not included with TV set, please purchase them by
yourself if necessary.
For 85"
1. Fix the larger side of P-Clip to the screw hole on the back of TV set with a M8×30 screw.
2. Fix the other side of P-Clip to the wall or pillar.
screw hole
P-Clip
Screw
Select a suitable screw hole
based on the actual situation.
