Indicators showing the battery's state of health
To check the battery's state of health, press the release button and hold it down for longer than
three seconds. The system does not detect a potential malfunction of the battery due to misuse, for
example battery dropped or pierced, external heat damage, etc.
Status Meaning
All LEDs show in sequence, followed by one (1)
LED showing constantly green.
The battery can remain in use.
All LEDs show in sequence, followed by one (1)
LED quick-flashing yellow.
The check to ascertain the battery's state of
health did not complete. Repeat the procedure,
or consult Hilti Service.
All LEDs show in sequence, followed by one (1)
LED showing constantly red.
If a connected product can still be used, the
remaining battery capacity is below 50 %.
If a connected product can no longer be used,
the battery has reached the end of its useful life
and has to be replaced. Consult Hilti Service.
Technical data
The nibbler comes with the SPNCN, SPNRN or SPNRL accessory tool as standard. The individual
accessory tools are also available as optional accessories and are compatible with every as-delivered
version of the power tool.
SPN 6-22
SPNCN SPNRN SPNRL
Product generation
02 02 02
Rated voltage
21.6 V 21.6 V 21.6 V
Weight without battery
2 kg
(4 lb)
2 kg
(4 lb)
2.2 kg
(4.9 lb)
Stroke rate at idle speed
620 /min …
1,370 /min
620 /min …
1,370 /min
620 /min …
1,370 /min
Starting hole diameter
17 mm
(0.7 in)
24 mm
(0.9 in)
24 mm
(0.9 in)
Smallest radius for curved cut-
outs
4.0 mm
(0.16 in)
•/• •/•
Radius
•/• 50 mm
(2.0 in)
50 mm
(2.0 in)
Cutting track width
8.0 mm
(0.31 in)
5.0 mm
(0.20 in)
5.0 mm
(0.20 in)
Permissible steel thickness, steel
up to 400 N⁄mm²
2.0 mm / 14 ga
(0.08 in / 14 ga)
2.0 mm / 14 ga
(0.08 in / 14 ga)
2.0 mm / 14 ga
(0.08 in / 14 ga)
Permissible steel thickness, steel
up to 600 N⁄mm²
1.5 mm / 16 ga
(0.06 in / 16 ga)
1.5 mm / 16 ga
(0.06 in / 16 ga)
1.5 mm / 16 ga
(0.06 in / 16 ga)
Permissible steel thickness, steel
up to 800 N⁄mm²
1.0 mm / 20 ga
(0.04 in / 20 ga)
1.0 mm / 20 ga
(0.04 in / 20 ga)
1.0 mm / 20 ga
(0.04 in / 20 ga)
Permissible material thickness,
aluminum up to 250 N⁄mm²
2.5 mm / 10 ga
(0.10 in / 10 ga)
3.0 mm / 9 ga
(0.12 in / 9 ga)
3.0 mm / 9 ga
(0.12 in / 9 ga)
