1.2.2 Overview of Type II Camera
Lens
Main Body
Bracket
Video Cable
Power Cord
Switch Button
Microphone
Figure 1-2 Overview of Type II Camera
Notes:
Press and hold the switch button for 5 seconds to
switch the video output. Four kinds of video outputs
are available: TVI, AHD, CVI, and CVBS
1.2.3 Overview of Type III Camera
Enclosure
Base
Installation
Plate
Main Body
Video Cable
Power Cord
Switch Button
Microphone
Figure 1-3 Overview of Type III Camera
Notes:
Press and hold the switch button for 5 seconds to
switch the video output. Four kinds of video outputs
are available: TVI, AHD, CVI, and CVBS
1.2.4 Overview of Type IV Camera
DC12VIN
Base
Set Screw
Enclosure
Main Body
Switch Button
Power Cord
Video Cable
Microphone
Figure 1-4 Overview of Type IV Camera
Notes:
Press and hold the switch button for 5 seconds to
switch the video output. Four kinds of video outputs
are available: TVI, AHD, CVI, and CVBS
1.2.5 Overview of Type V Camera
Base
Installation Plate
Enclosure
Main Body
Switch Button
Power Cord
Video Cable
Microphone
Figure 1-5 Overview of Type V Camera
Notes:
Press and hold the switch button for 5 seconds to
switch the video output. Four kinds of video outputs
are available: TVI, AHD, CVI, and CVBS
