Monitor User Manual
Figure 4.
4 Input Source
4.5 Main Menu
4.5.1 Image Settings
Purpose:
You can adjust the picture parameters by switching image modes and adjust the values of contrast,
brightness, color temperature, auto adjust, color adjust.
Steps:
1. Press 1 key to enter the main menu interface as shown below.
2. Press 1 key to enter the setting you want.
3. Press ◄ or ► to adjust the value. It applies for adjusting contrast, brightness, color temp and
other parameters.
Contrast, Brightness: Press ◄ or ► to set the contrast, the range varies from 0-100.
Color temperature : Press ◄ or ► to set the color temperature you need.
Gray indicates that under current mode or current input source condition it is not adjus
table;
Yellow ind
icates that
it is adjustable.
4.Press 2 key to return to the main menu after accomplishing the adjustment.
Figure 4.5.1 Image Settings
Warm Standard
Cool User
1920×1080 60Hz
5
