4 EN
Using the appliance
A
Installation with external opening
If you have an outlet to the outside, your cooker hood can be connected as below picture by
means of an extraction duct (enamel, aluminum, flexible pipe or nonflammable material with
an interior diameter of 120mm).
1. Before installation, turn the unit off and unplug it from the outlet.
2. The cooker hoods should be placed at a distance of 65-75cm from the cooking surface for
best effect. See Pic 1.
3. To install onto the wall, drill 4 holes of Ø 8mm at a suitable place according to the centre
distance of the holes in the back of the cooker hood. See Pic 2.
4. Insert the wall plugs into the holes.
5. Insert the ST4*30mm screws into the wall plugs and tighten.
6. Put up the cooker hood onto the fixed screws.
7. Use the attached accessories enclosed to turn the safety screws into the two holes inside
