©2016 Hestan Commercial Corporation
14
EN
CART & GRILL ASSEMBLY
(continued)
17. Your new Hestan cart comes with doors pre-installed and adjusted at the factory. However,
it may be necessary to adjust them once the grill head is installed. As shown below, remove
the damper to access the adjustment screws. If for some reason you wish to detach the door,
pinch the back of the hinge to un-clip it from the mounting base. The door may now be
removed.
PRY UP HERE TO
REMOVE DAMPER
DOOR
MOUNTING
BASE
CART WALL
STRUCTURE
DAMPER
DOOR
MOUNTING
BASE
CART WALL
STRUCTURE
PINCH HERE
TO UN-CLIP
HINGE
18. Hestan doors feature 3-way adjustable hinges. It is recommended to do the height adjustment
first. Loosen the top & bottom screw on each mounting base, then use the height adjustment
screw shown below to fine-tune the vertical height of the door in the cart. Tighten the top and
bottom screws when done.
HEIGHT
ADJUSTMENT
