CJ
- Rotate KNOB to highlight one available option, press to select:
(FREQUENCY>SLOPE).
FREQUENCY (to set the SUB low pass cutoff filter frequency)
Rotate the KNOB to highlight the desired value (60Hz>80Hz>100Hz>FULL), press to select.
SLOPE (to set the SUB low pass filter slope)
Rotate the KNOB to highlight the desired value (-12dB/oct>-24dB/oct), press to select.
SUBW POLARITY (to set the SUB phase)
- Rotate the KNOB to highlight ( 0° or 180°), press to select.
MAX VOLUME LIMIT (to limit the maximum volume output of this zone).
- Rotate KNOB to adjust the desired Volume level limit from 0 to 40.
POWER ON VOLUME LIMIT (to limit the maximum volume level of this zone when the head unit is
turned ON).
- Rotate KNOB to adjust the desired Volume level upon turn on from 0 a 40.
LEVEL CONTROL MODE
Rotate KNOB to highlight one of the available options, press to select:
- VARIABLE (default): the volume level of the signal output from this audio zone is variable and can be
controlled via the volume mixer (AUDIO ZONE LEVEL).
- FIXED @4Vrms: the level of the output signal from this audio zone is fixed at 4Vrms. It will no longer
be possible to change the volume level for this zone until the “Variable” mode is selected.
- FIXED @2Vrms: the level of the output signal from this audio zone is fixed at 2Vrms.
It will no longer be possible to change the volume level for this zone until the “Variable” mode is
selected.
- FIXED @1Vrms: the level of the output signal from this audio zone is fixed at 1Vrms.
It will no longer
be possible to change the volume level for this zone until the “Variable” mode is
selected.
- OFF: this audio zone is off. This zone will no longer play any sound until “Variable” or “Fixed” mode is
selected
ZONE 4 (ZONE 4 and SPEAKER OUT settings).
- RotateKNOB to highlight one available option, press to selector to enable
or disable
this function.
(ZONE RENAME > EQUALIZER > BALANCE > LOUDNESS > CROSSOVER (HPF) > SUBWOOFER >
MAX VOLUME LIMIT > POWER ON VOLUME LIMIT > LEVEL CONTROL MODE)
ZONE RENAME (to create a desired name for this audio zone, to facilitate identification).
Use KNOB to enter a desired name for this audio zone (max 10 characters).
