Speaker kits Ci3 K165.2FM-S2 MK2 Ci3 K200.2FM-S3 MK2 Ci3 K200FM.2-S2 MK2
Power RMS / Max. P 100 / 150 Watts 100 / 150 Watts 100 / 150 Watts
Frequency response 60 Hz - 25,000 Hz 50 Hz - 25,000 Hz 50 Hz - 25,000 Hz
Impedance Z 2 Ω 3 Ω 2 Ω
Sensitivity SPL
94 dB @ 2.83V / 1m
88 dB @ 1W / 1m
94 dB @ 2.83V / 1m
90 dB @ 1W / 1m
96 dB @ 2.83V / 1m
90 dB @ 1W / 1m
Outer diameter
(
more data page 11 et sqq.)
Ø Tweeter: 32.0 mm / 1.26”
Woofer: 165.0 mm / 6.50”
Tweeter: 32.0 mm / 1.26”
Woofer: 195.0 mm / 7.68”
Tweeter: 32.0 mm / 1.26”
Woofer: 195.0 mm / 7.68”
Installation diameter
(
more data page 11 et sqq.)
Ø Tweeter: 32.0 mm / 1.26”
Woofer: 142.0 mm / 5.59”
Tweeter: 32.0 mm / 1.26”
Woofer: 173.5 mm / 6.83”
Tweeter: 32.0 mm / 1.26”
Woofer: 173.5 mm / 6.83”
Installation depth
(
more data page 11 et sqq.)
Tweeter: 9.8 mm / 0.39”
Woofer: 60.7 mm / 2.39”
Tweeter: 9.8 mm / 0.39”
Woofer: 63.7 mm / 2.51”
Tweeter: 9.8 mm / 0.39”
Woofer: 63.7 mm / 2.51”
Dimensions cross-
over
103.3 x 50.4 x 25.0 mm /
4.07 x 1.98 x 0.98”
103.3 x 50.4 x 25.0 mm /
4.07 x 1.98 x 0.98”
103.3 x 50.4 x 25.0 mm /
4.07 x 1.98 x 0.98”
Woofer
Impedance Z 2 Ω 3 Ω 2 Ω
DC resistance Re 1.8 Ω 3.0 Ω 1.8 Ω
Resonance frequency Fs 74 Hz 67 Hz 72 Hz
Mechanical Q factor Qms
3.92 4.25 4.56
Electrical Q factor Qes
0.92 0.93 1.09
Total Q factor Qts
0.74 0.76 0.88
Compliance Cms
370 μm/N 300 μm/N 230 μm/N
Equivalent air volume Vas
8.8 L 19.0 L 14.5 L
Force factor B*l
3.4 Tm 5.1 Tm 4.0 Tm
Cone area Sd
133 cm
2
214 cm
2
214 cm
2
Moving mass Mms 12.5 g 18.8 g 20.8 g
Mechanical resistance Rms
1.48 kg/s 1.87 kg/s 2.07 kg/s
Voice coil diameter Ø
25 mm 25 mm 25 mm
Voice coil winding
height
11.3 mm 11.6 mm 11.9 mm
Max. linear excursion Xmax
+/- 3.7 mm +/- 3.8 mm +/- 4.0 mm
Tweeter
Impedance Z 4 Ω 4 Ω 4 Ω
Resonance frequency Fs 1800 Hz 1800 Hz 1800 Hz
Voice coil diameter Ø
20 mm 20 mm 20 mm
Features
Tweeter
Ultra compact, aluminum
dome, neodymium magnet
and
Ultra compact, aluminum
dome, neodymium magnet
and
Ultra compact, aluminum
dome, neodymium magnet
and
Woofer Paper with Cenosphere
coating
,
terminal and
Paper with Cenosphere
coating
,
terminal, and
grille
Paper with Cenosphere
coating
,
terminal, and
grille
Crossover Tweeter: 12 dB highpass,
protection and
level adjustment
Woofer: 6 dB lowpass
Tweeter: 12 dB highpass,
protection and
level adjustment
Tweeter: 12 dB highpass,
protection and
level adjustment
