MiniVent M1/100/120
Installation and Operation Instructions
4
CHAPTER 4
FUNCTION
3.2 Accessories
MVB Operating/speed switch 0-1-2 Ref.No. 6091
WES 100 Wall installation kit Ref.No. 0717
WES 120 Wall installation kit Ref.No. 0486
MF 100 Mounting flange Ref.No. 6188
TWH 100 Telescopic wall sleeve Ref.No. 6352
TWH 120 Telescopic wall sleeve Ref.No. 6353
MBR Mounting cover strip Ref.No. 0281
3.3 Product service life
This unit is designed for a product service life of at least 40,000 h, in case of S1 operation with maximum power in the
maximum permissible ambient temperature.
3.4 Dimensions
M1/100 M1/120
4.0 Functional description M1/100/120
The M1/100/120 MiniVent mini fan can be selectively operated with a commercially available light switch in stage 1 or
stage 2. By controlling the speed with the on/off switch MVB (Accessories), the M1/100/120 MiniVent can be used in
two settings.
fig.2fig.1
All dimensions in mm All dimensions in mm
UK
