www.heinner.com
17
3. Rear grille installation
3.1. Please take out the grille lock nut and blade lock nut from the motor shaft first.
Operation essential: First fix the motor shaft by hand and then loosen the blade lock nut
clockwise. Then unscrew the lock nut of the grille counterclockwise.
3.2. Hang the rear grille on the motor; rotate the grille lock nut clockwise to lock the rear
grille
4. Blade installation
Fix the blade on the motor shaft with the blade lock nut.
Tighten
Loosen
Fix rear grille
Align bumps on the front shell
of the motor and water drop
hole in the rear grille
