14
A (mm)
B (mm)
C (mm)
D (mm)
E (mm)
F (mm)
G (mm)
268 +/- 4
500 +/- 4
50min
50min
50min
50min
3 min
Under any circumstances, make sure the Induction cooker hob is well ventilated and the air inlet and outlet
are not blocked. Ensure the induction cooker hob is in good working state. As shown below.
Note: The safety distance between the hotplate and the cupboard above the hotplate should be at least
760 mm.
A (mm)
B (mm)
C (mm)
D
E
760
50
20
Air intake
Air exit 5 mm
WARNING: Ensuring Adequate Ventilation
Make sure the induction cooker hob is well ventilated and that air inlet and outlet are not blocked. In order
to avoid accidental touch with the overheating bottom of the hob, or getting unexpectable electric shock
during working, it is necessary to put a wooden insert, fixed by screws, at a minimum distance of 50 mm from
the bottom of the hob. Follow the requirements below.
There are ventilation holes around the outside of the hob. YOU MUST ensure these holes are not blocked
by the worktop when you put the hob into position.
• Be aware that the glue that joins the plastic or wooden material to the furniture, has to resist to
temperature not below 150°C, to avoid the unstuck of the paneling.
• The rear wall, adjacent and surrounding surfaces must therefore be able to withstand an temperature of
90°C.
Before installing the hob, make sure that:
• The work surface is square and level, and no structural members interfere with space requirements.
• The work surface is made of a heat-resistant and insulated material.
• If the hob is installed above an oven, the oven has a built-in cooling fan.
• The installation will comply with all clearance requirements and applicable standards and regulations.
