www.heinner.com 105W, 50Hz, 220-240V
4
IV. INSTALATION
METHOD A (VENT OUTSIDE)
If you have an outlet to the outside, your cooker hood can be connected as below
picture by means of an extraction duct (enamel, aluminum, flexible pipe or
inflammable material with an interior diameter of 150mm)
1. Before installation, turn the unit off and unplug it from the outlet.
2. The cooker hood should be placed at a distance of 65~75cm above the cooking
plane for best effect.
3. Fix the extensible tube on the hood, and put the cooker hood on the hook, and keep
it in line. Then fix it with screws
4. Fix the chimney bracket to the chimney, place the chimney on the casing, and
lead the pipe outside
